WHEATHEART - GHR & WHR GRAIN AUGERS 4. T RANSPORT & P LACEMENT
GRAIN AUGERS SD 4.2. P LACEMENT P ROCEDURE
30662 R1 37
4. Before connecting the hydraulic hose, ensure that the quick connect couplers
on auger and tractor are clean and free of dirt by wiping with a cloth.
5. After connecting hydraulic hose, visually check it for leaks, binding,
flattening, kinks or wear.
Important: The 130 auger is elevated with two 4” single-acting hydraulic cylinders and
cables. The following table lists the PSI required to raise specific auger sizes as
determined by WHEATHEART testing.
These tests were conducted using a hydraulic pressure gauge (4000 PSI
maximum rating) and are solely intended to be used as a guide. The PSI require-
ments for a specific auger may vary slightly. Should your auger require a signifi-
cantly higher PSI to raise, contact either your dealer or WHEATHEART.
6. Approximate quantity of hydraulic fluid required to raise auger is as follows:
NOTICE
Dirt in the hydraulic system can damage the cylinder o-rings
causing leakage and the possible failure of the system.
Table 4.1
AUGER PSI KPa
130-51' 1400 9653
130-61' 1600 11032
130-71' 1800 12411
CAUTION
Do not disconnect hydraulic coupler when
system is pressurized.
W130-51' 12.4 litres (3.28 US gallons)
W130-61' 15 litres (3.96 US gallons)
W130-71' 18 litres (4.76 US gallons)
