31 System Configuration ~ Audio Routing
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
numerical value directly in the window). The attenuation range is from 0 to -60dB.
Click Close to exit. Note that the level control you have selected for the cross point
is indicated numerically in the cross point cell.
The Cross Point shortcut menu also allows you to copy and paste the current
Cross Point configuration, including attenuation, to other cross points. You can copy
a single cell or the entire matrix using the shortcut menu options. To copy and
paste a cross point to multiple cross points, press Ctrl+C to copy (or right-mouse
click). Then press Ctrl+V while holding down the left-mouse button and drag the
mouse over the cross points to which you want to copy the settings.
Matrix report
When you finish audio routing, you can print a detailed report of the matrix using the
Print Matrix option on the shortcut menu (see Figure 3.22).
The Print Matrix Report window displays all matrix routing and cross point
information. Click the Print icon button to print the report.
Figure 3.23. Cross Point window
Figure 3.24. Matrix Report window
