27
Irving Oil
10004000
Code# Part Description IRFSDV24 IRFSDV34
20 Fan Assembly with bracket 54103 54103
21 Remote ON/OFF Switch 53606 53606
22* Wiring Harness - Remote Switch 57265 57265
23* Remote ON/OFF Switch Kit (includes bracket) 53859 53859
24 Window Frame Assembly (complete with glass) 10003973 10003966
25* Window Glass with Gasket Assembly Kit 10003974 10003965
26* Window Glass Gasket Kit 10001983 10001983
27 Front Louvre Assembly 10003537 10001370
28 Cabinet Side Door 10003541 10001792
29 Control Door Assembly 10003539 10001790
30 Clamp 10000949 10000949
31 Antennae --- 20003561
32 Top Grill Panel 10001791 10001791
33* Magnet Ceramic Side Doors 10001705 10001705
34 Screen Cabinet Top 10001749 10001749
35* Plate Relief with Gasket Assembly 10002862 20002862
36* Front Grate Assembly - Charcoal Gray 10003535 ---
37 Sensor Fan 51704 ---
38 Speed Control 51738 ---
39 Thermocouple SIT 53373 ---
REPLACEMENT PARTS LIST
Note: Items marked ‘*’are not shown in the following parts pictorial.
