OPTIONAL GOLD TRIM KIT
OPTIONAL FRAME WINDOW TRIM KITS
A decorative gold plated window trim kit Model
#VT1G00 RFSDV24TKG is available for the IRSFD24
Freestanding Fireplace.
The kit contains:
1 Gold-plated Window Trim
4 Magnets
INSTALLATION PROCEDURE
1.
Unpack the kit and confirm all parts are present.
2. Remove all the protective plastic wrap from the
gold window trim.
3. Attach the magnets to the trim (Fig. 37).
4. Position trim against the fireplace window frame
assembly. The trim will be held in place by
the magnets.
NOTE: Only the gold cleaner is allowed to be used for
this window trim.
GOLD CLEANING: Clean the gold trim with a soft
clean cloth slightly dampened with gold cleaner
product and buff with a soft dry cloth.
DO NOT use brass polish or household cleaners as
these products will damage the trim.
Gold cleaner products can be obtained from any
fireplace dealer stores.
MAGNETS LOCATION MAGNETS LOCATION
ALWAYS UP AFTER ALWAYS UP AFTER
INSTALLING INSTALLING
BIG RADIUS OF BIG RADIUS OF
THE TRIM THE TRIM
Fig. 37
Decorative brass window trim kits are available for the
IRSFDV34 Freestanding Fireplace.
Model Style
RFSDV34TKA - Antique Brass
RFSDV34TKD - Polished Brass
RFSDV34TKD - Pewter
INSTALLATION PROCEDURE
1.
Unpack the kit and confirm all parts are present.
2. Remove all the protective plastic wrap from the
brass components.
3. Attach the magnets to the trim (Fig. 38). (Antique
Brass or Polished Brass only
4. Position trim against the fireplace window frame
assembly. The trim will be held in place by
the magnets.
5. Fit the brass rings in place around any visible
vent joints.
It is very important to remove all the protective
wrap from the brass components before fitting
them to the fireplace or venting.
BRASS CLEANING: Clean the brass trim
with a soft clean cloth, slightly dampened
with lemon oil and buff with a soft dry cloth.
Lemon oil may be obtained at
supermarkets or hardware stores.
DO NOT use brass polish or household cleaners as
these products will damage the tirm.
Fig. 38
Place magnets here
REMOTE CONTROLS
These remote controls are available as an option only
on fireplaces fitted with RN/RP gas control valves.
IRFSDV24 model only.
MRC1 On/Off Button Remote Control
MRC2 Temperature Control Remote
MRC3 Temperature Control w/digital
display & 24 hour program-
mable clock
IMT Wall Mounted Thermostat
