16
Irving Oil
10004000
CRIMPED END VENTING COMPONENTS
Starter Kit-Model 7FSDVSK-Sidewall Venting
Starter Kit-Model 7TDVSKV-Vertical Venting
for 7DVSKV-A order 1/12 to 6/12 roof pitch
for 7DVSKV-B order 7/12 to 12/12 roof pitch
for 7DVSKV-F order flat roof
Starter Kit-Model 7FSDVSKS-Snorkel Kit
for Below Grade Installation
45˚ elbow kit
7FSDVT45G for Vertical Installation Offsets
90˚ Transition elbow kit
7DVRT90 for Vertical Sidewall Applications
or through-the-roof.
Telescopic vent sections
7DVP610 -6” to 10” adjustable length
7DVP1018 -10” to 18” adjustable length
7DVP1834 -18” to 34” adjustable length
7DVP3466 -34” to 66” adjustable length
Pipe sections for vertical or horizontal venting
Model 7DVP8” - 4 per box
Model 7DVP12” - 4 per box
Model 7FSDVP24G
Model 7DVP36”
Model 7FSDVP48G
Firestop Spacer
Model 7DVFS
Attic Insulation Shield
Model 7DVAIS
Vertical/Horizontal Combination Offset Support
Model 7DVCS
