26
Irving Oil
10004000
Code # Part Description IRFSDV24 IRFSDV34
1 Log Set Complete 10003538 100001763
1a Log ember bed --- KR7
1b Log - Front left KR13 KR8
1c Log - Front right KR14 KR9
1d Log - Rear — KR10
1e Log - Top left — KR11
1f Log - Top right — KR12
1g Log - Rear left KR15 ---
1h Log - Rear right KR16 ---
2* Lava Rock 57897 57897
3 Burner Housing Assembly (with tiles) 10003559 10001272
4* Ceramic Tile (singular) 57803 57803
5a* Orifice, Main Burner - Nat. Refer to Rating Plate
5b* Orifice, Main Burner - Prop. Refer to Rating Plate
5c* Orifice, Front Burner - Nat Refer to Rating Plate
5d* Orifice, Front Burner - Prop Refer to Rating Plate
6a* Orifice, Top Convertible Pilot - Nat 10002268 10002268
6b* Orifice, Top Convertible Pilot - Prop 10002269 10002269
7a* Orifice, Radio Frequency Pilot - Nat --- 20000908
7b* Orifice, Radio Frequency Pilot - Prop --- 20000907
8a Pilot Assembly, Radio Frequency - Nat --- 20002266
8b Pilot Assembly, Radio Frequency - Prop --- 20002268
9a Pilot, Assembly, 3 way DV Top Con. - Nat 10002264 10002264
9b Pilot, Assembly, 3 way DV Top Con. - Prop 10002265 10002265
9c Pilot, Assembly, PSE - Nat. --- 10001741 (RMH)
9d Pilot, Assembly, PSE - Prop. --- 10001742 (RMH)
10 Pilot with Electrode & Cable, PSE --- 10002501
11a Pilot tube with fittings, PSE --- 10003279
11b Pilot tube with fittings, SIT 10001296 ---
12* Manifold Tube with fittings 10002492 57318
13a Thermopile, Radio Frequency --- 20002400
13b Thermopile, RN & RP 53373 53373
14 Igniter (Piezo), Honeywell valve 20000062 20000062
15 Transmitter --- 20002047
16* Manifold Assembly 10003207 10000824
17 Electrode igniter with cable 24” 10001297 10001297(RMH)
18a Valve, Honeywell Radio Frequency - Nat --- 20003719
18b Valve, Honeywell Radio Frequency - Prop --- 20003720
18c Valve, Honeywell, RN 10001782 10001782 (RMH)
18d Valve, Honeywell, RP 10001759 10001759 (RMH)
19* Electric Cord Set. Radio Frequency Valve --- 20002541
REPLACEMENT PARTS LIST
