2.2.8.9 Display Charger Identification Number
Chargers that are part of an I’m Cool Battery Selection System or a TOBi
®
Battery Management System have a unique
identifying number. To view this ID number, press I.D. The display shows ‘CHARGER ID NO’ followed by ‘ID:’ and the
charger ID number. If no number is set, the display shows ‘9999’.
2.2.8.10 Display Time of Day
To view the current time, press CLOCK. The display shows ‘TIME OF DAY’ followed by ‘TD:’ and the time-of-day in
24-hour format.
2.2.8.11 Display Battery Temperature in ˚F
2.2.1.1.
To view the battery temperature in ˚F, press TEMP. The display shows ‘TEMPERATURE (°F)’ followed by
‘TM:’ and the current battery temperature in degrees F. Note: A thermal sensor or Tobi® PI must be installed and
connected properly for the control to read and display temperature, otherwise the temperature is displayed as 255°.
2.2.8.12 Display Battery Temperature in ˚C
2.2.1.2.
To view the battery temperature in ˚C, press TEMP twice. The display shows ‘TEMPERATURE (°C)’
followed by ‘TM:’ and the current battery temperature in degrees C. Note: A thermal sensor or Tobi® PI must be
installed and connected properly for the control to read and display temperature, otherwise the temperature is
displayed as 255°.
2.2.8.13 Display Percent Amp-Hours Returned
To view amp-hours returned as a percentage of the battery size press % RET. The display shows ‘% AH RETURNED’
followed by ‘PR:’ and the percentage of amp-hour capacity returned for the current or last charge cycle.
2.2.8.14 Display Trip Point
To view the cell voltage at which the battery is 80% charged, press 80%. The display shows ‘80% TRIP POINT’ followed
by ‘TP:’ and the 80% voltage in volts per cell.
2.2.8.15 Perform Lamp Test
To check the display for bad segments press TEST. All segments in the display should light.
2.2.9 ADDITIONAL KEYPAD FUNCTIONS
The following additional keypad functions are available:
F3 (Low Battery) Override
Press STOP while the F3 message (Low Battery) displays.
Water Valve Test
Verify the watering parameter ‘WA’ is ‘ON’. Press 7 and STOP simultaneously to toggle water valve on and off. If left on,
valve turns off after 3 minutes.
Reset
Press 4, 5, and 6 simultaneously. Resets and restarts the processor.
Load Default Values
Disconnect battery. Press 1, 2, and 3 simultaneously. This removes all program changes and loads the default parameter
values. The display shows ‘NO ALGORITHM SET’. The control must then be re-programmed as described in
‘PROGRAMMING’ above.
