Viking Pump TSM610: Offset Gear Reducers - Manual (Page 8)

SECTION TSM
PAGE
ISSUE
VIKING PUMP, INC. • A Unit of IDEX Corporation •
Cedar Falls, IA 50613 USA
© 3/2013 Viking Pump Inc.
All rights reserved
TECHNICAL SERVICE MANUAL
WARRANTY
Viking warrants all products manufactured by it to be
free from defects in workmanship or material for a
period of one (1) year from date of startup, provided
that in no event shall this warranty extend more than
eighteen (18) months from the date of shipment from
Viking. The warranty period for Universal Seal series
pumps ONLY (Universal Seal models listed below) is
three (3) years from date of startup, provided that in
no event shall this warranty extend more than forty-two
(42) months from the date of shipment from Viking.
UNDER NO CIRCUMSTANCES SHALL VIKING BE
LIABLE UNDER THIS WARRANTY OR OTHERWISE
FOR SPECIAL, INCIDENTAL, INDIRECT,
CONSEQUENTIAL OR PUNITIVE DAMAGES OF ANY
KIND, INCLUDING, BUT NOT LIMITED TO, LOST
OR UNREALIZED SALES, REVENUES, PROFITS,
INCOME, COST SAVINGS OR BUSINESS, LOST OR
UNREALIZED CONTRACTS, LOSS OF GOODWILL,
DAMAGE TO REPUTATION, LOSS OF PROPERTY,
LOSS OF INFORMATION OR DATA, LOSS OF
PRODUCTION, DOWNTIME, OR INCREASED
COSTS, IN CONNECTION WITH ANY PRODUCT,
EVEN IF VIKING HAS BEEN ADVISED OR PLACED
ON NOTICE OF THE POSSIBILITY OF SUCH
DAMAGES AND NOTWITHSTANDING THE FAILURE
OF ANY ESSENTIAL PURPOSE OF ANY PRODUCT.
THIS WARRANTY IS AND SHALL BE VIKING’S SOLE
AND EXCLUSIVE WARRANTY AND SHALL BE IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, ALL WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND
NON-INFRINGEMENT ALL OF WHICH OTHER
WARRANTIES ARE EXPRESSLY EXCLUDED.
See complete warranty at www.vikingpump.com.
610
8
F
“C” Size helical Reducer horsepower Table Part No./Ratio (3-551-056-221/2.21:1) (3-551-008-331/3.31:1)
(3-551- 009-421/4.21:1) (3-551-010-508/5.08:1) (3-551-011-624/6.24:1) (3-551-012-795/795:1) (3-551-032-280/2.80:1)
hIGh SPEED
ShAFT
INPUT RPM (1)
VIkING GEAR REDUCER RATIOS “C” SIzE
2.21:1 2.80:1 3.31:1 4.21:1 5.80:1 6.24:1 7.95:1
1750
780 640 520 420 350 280 220 LOW SPEED SHAFT RPM
49.8 43.5 39.0 32.4 26.6 19.7 18.0 MAXIMUM REDUCER HP
1450
640 520 420 350 280 230 180 LOW SPEED SHAFT RPM
45.3 36.6 32.8 27.2 22.3 16.7 15.2 MAXIMUM REDUCER HP
1150
520 420 350 280 230 190 145 LOW SPEED SHAFT RPM
40.1 30.0 26.8 22.2 18.2 13.8 12.6 MAXIMUM REDUCER HP
950
420 350 280 230 190 155 120 LOW SPEED SHAFT RPM
29.1 24.7 22.1 18.3 15.0 11.4 10.4 MAXIMUM REDUCER HP
(1) For input speeds higher than 1750 RPM, consult the factory.
VIkING® hELICAL GEAR REDUCERS
“A”, “B”, AND “C” SIzES
