Unitec ReachFree ID for C-Start User Manual
Page 14

R E A C H F R E E I D
Document Number:
RFID1001
10
Document Name:
Unitec RFID Field Retrofit Installation Guide
1.
Run the data cable down thr
u the unit’s conduit and up to the mounted reader.
2.
Plug the female end of the in-
line connector on the 30’ data cable into the male end
of the in-line connector on the reader. To ensure a tight, water-proof connection, fit
the two ends together, press firmly and turn the ends to lock them together.
3.
Connect the other end of the data cable with the 6-pin Phoenix connector to the J2
connector on the RFID board
4.
Plug the power supply into the J1 power connector on the RFID board and the
power supply cord into an outlet on the power supply panel at the back of the unit.
5.
Connect the 4-pin I2C cable to the J3 4-pin connector on the RFID board. Connect
the other 4-pin connector to the CN3 connector at the bottom of the carrier board on
the right wall of the unit.
