Mount RFID Board and Connect Cables

Portal TI Installation

If installing the board inside a Portal with coin or bill dispensing, the RFID board mounts to the side
of the bill dispenser/coin hopper cage inside the entry unit.

Figure 8. RFID Board Location in Portal with Coin/Bill Dispensing

If installing the board inside a cashless Portal, the RFID board mounts to the top back wall of the
unit to the left of the power supply tower.

Figure 9. RFID Board Location in Cashless Portal
