22
GAS METAL ARC WELDING (GMAW)
1. Install and connect unit according to the Installation
section.
2. Install and connect wire feed system according to
wire feeder installation guide.
3. Wear gloves, welding helmet and protective
clothing.
4. Connect work lead to the negative CV terminal.
5. Place the process selector switch in CV position.
6. If remote voltage control is not used, place the
Amperage/Voltage switch in panel position.
7. Rotate Amperage/Voltage control to desired position.
8. Turn on shielding gas supply and set desired flow
rate.
9. Begin welding.
SELECTING WELD CABLE SIZES
Weld cable size (AWG) is based on either a 4 volts or less
drop or a current density of more than 300 circular mils
per ampere.
100ft
(30 m)
150ft.
(45 m)
200ft.
(60 m)
250ft.
(70 m)
Welding
Amperage
60-100%
Duty Cycle
10-100% Duty Cycle
100 4 4 3 2
150 3 2 1 1/0
200 2 1 1/0 2/0
250 1 1/0 2/0 3/0
300 1/0 2/0 3/0 4/0
