SECTION 2: TECHNICAL SPECIFICATIONS
2.01 Specifications
The Thermal Arc Raider 10,000 Pro is a gasoline engine driven DC welding generator with selectable Constant Current (CC)
and Constant Voltage (CV) output characteristics. This unit is designed for use with Shielded Metal Arc Welding (SMAW),
Gas Metal Arc Welding (GMAW), and GAS Tungsten Arc Welding - (GTAW) processes.
Specifications
DC
Amperage Range 15 – 270
Duty Cycle 270 @ 60%
AC/DC welding current 250 @ 100%
Volt Range CV Mode 16 – 30
OCV CC Mode 70 VDC
Auxiliary Power
Single Phase
115 2ea GFCI Duplex Receptacles 3.5Kva
Single Phase 115/240 8.5Kva
Three Phase 460 10Kva
Engine
Make/Type
HONDA
Model series GX 620K1
Number of cylinders 2
Displacement 614 cc.
Power 20 HP
Engine Speed 3750 rpm no load
Engine speed 2600 rpm Idle
Cooling system Air
Oil capacity 1.5 l. - 0,42 gl.
Fuel capacity 37.5 l. - 10 gl.
Fuel consumption 5.2 l/h – 1.4 gl./Hr
Battery 12V 340A
