Tweco 300 TS Arcmaster(Feb2006) User Manual
Page 30

24
4.04 Weld Parameters for ArcMaster 300 TS
Weld
Mode
Weld
Parameter
Parameter Range
Factory
Setting
Incremental
Unit
STICK
HF
TIG
LIFT
TIG
PRE-FLOW
0.0 to 1.0 sec
0 sec
0.1 sec
No
Yes
Yes
HOT START
0 to 70A
20A
1A
Yes
Yes
No
INITIAL CUR.
5 to 300A
30A
1A
No
Yes
Yes
UP SLOPE
0 to 15 sec
1 sec
0.1 sec
No
Yes
Yes
PEAK CUR.
5 to 300A
120A
1A
No
Yes
Yes
WELD CUR
(TIG)
5 to 300A
80A
1A
No
Yes
Yes
WELD CUR (STICK)
5 to 300A
80A
1A
Yes
No
No
SPOT TIME
0.5 to 5.0 sec
2 sec
0.1 sec
No
Yes
Yes
PULSE WIDTH
15 to 80%
50%
1%
No
Yes
Yes
PULSE FREQ.
0.5 to 500Hz
100.0Hz
See
Table
No Yes
Yes
DOWN SLOPE
0 to 25 sec
3 sec
0.1 sec
No
Yes
Yes
CRATER CUR.
5 to 40A
30A
1A
No
Yes
Yes
POST-FLOW
0.0 to 60 sec
10 sec
0.1 sec
No
Yes
Yes
Table 5 – Weld Parameters for ArcMaster 300 TS
PULSE FREQ.
Range
Incremental Unit
0.5 to 20Hz
0.1Hz
20 to 100Hz
1Hz
100 to 500Hz
5Hz
Table 6 –
PULSE FREQ.
Range and Incremental Units
