APPENDIX
NOTES
1. Recommended plasma pressure setting for 60 ft (18.3 m) total hose length (extension plus leads). For every 10 ft (3 m) of additional
hose length add 2.5 psi (0.17 bar) to the plasma pressure setting.
2. Recommended secondary pressure setting for 60 ft (18.3 m) total hose length (extension plus leads). For every 10 ft (3 m) of addi-
tional hose length add 1.0 psi (0.07 bar) to the secondary pressure setting.
3. Piercing materials 3/4 inch (19.1 mm) and over may shorten torch consumable parts life.
Metric Measurements
Oxygen Plasma Cutting Data Chart
Maximizer 300 Torch
Mild Steel - Underwater (Water Table)
Oxygen Plasma / Air Secondary
Electrode
Gas
Distributor
Tip End Cap Amperage
Output
Volts
Speed Standoff
Plasma
Pressure
Secondary
Pressure
Pierce
Delay
Pierce
Height
Cat. No. Cat. No. Cat. No. Cat. No. amps vdc m / min mm bar bar seconds mm
20-1015 20-0008 20-1031 20-1028 100 125 10.16 4.78 4.83 3.45 0.00 6.35
20-1015 20-0008 20-1031 20-1028 100 125 6.99 4.78 4.83 3.45 0.00 6.35
20-1015 20-0008 20-1031 20-1028 100 130 4.70 4.78 4.83 3.45 0.00 6.35
20-1015 20-0008 20-1031 20-1028 100 130 3.18 4.78 4.83 3.45 0.00 6.35
20-1015 20-0008 20-1031 20-1028 100 130 1.91 4.78 4.83 3.45 0.25 6.35
20-1016 20-0008 20-1032 20-1028 150 121 3.81 4.78 4.83 3.45 0.10 6.35
20-1016 20-0008 20-1032 20-1028 150 125 2.54 4.78 4.83 3.45 0.10 6.35
20-1016 20-0008 20-1032 20-1028 150 130 1.65 4.78 4.83 3.45 0.20 6.35
20-1016 20-0008 20-1032 20-1028 150 135 1.40 4.78 4.83 3.45 0.20 6.35
20-1016 20-0008 20-1032 20-1028 150 140 1.02 4.78 4.83 3.45 0.50 12.70
20-1017 20-0008 20-1033 20-1028 225 135 2.54 6.35 4.83 3.45 0.25 9.53
20-1017 20-0008 20-1033 20-1028 225 135 1.91 6.35 4.83 3.45 0.25 9.53
20-1017 20-0008 20-1033 20-1028 225 135 1.27 6.35 4.83 3.45 0.25 9.53
20-1017 20-0008 20-1033 20-1028 225 140 1.02 6.35 4.83 3.45 0.50 9.53
20-1018 20-1009 20-1034 20-1028 300 135 1.65 9.53 4.83 3.45 0.25 12.70
20-1018 20-1009 20-1034 20-1028 300 140 1.27 9.53 4.83 3.45 0.50 12.70
20-1018 20-1009 20-1034 20-1028 300 145 0.76 9.53 4.83 3.45 NR NR
20-1018 20-1009 20-1034 20-1028 300 145 0.51 6.35 4.83 3.45 NR NR
12.7
15.9
Material
Thickness
mm
1.6
31.8
19.1
25.4
15.9
19.1
38.1
3.2
4.8
6.4
9.5
19.1
25.4
6.4
9.5
12.7
