PARTS LISTS
6-14
Manual 0-4641
6
6.13 Torch Consumables
The illustration shows all SL100 torch consumable parts for use with the CutMaster 81 Automated Power
Supply.
Various front-end torch parts are available for different applications.
The Shield Cup Body with the Deflector Shield Cap provides extended parts life and improved resistance to reflected
heat.
The electrode and start cartridge are the same for all operations.
6.14 Torch Spare Parts Kits
Qty
Description
Catalog #
40-Amp Automated Machine Torch Spare Parts Kit, includes:
5-0054
3
Electrode
9-8215
5
30 Amp Tip
9-8206
5
40 Amp Standoff Tip
9-8208
1
Start Cartridge
9-8213
1
Shield Cup Body
9-8237
1
Shield Cap, Machine, 40 Amp
9-8245
1
Shield Cap, Deflector
9-8243
1
Ohmic Clip Kit
9-8224
1
Large O - Ring
8-3487
1
Small O - Ring
8-3486
60-Amp Automated Machine Torch Spare Parts Kit, includes:
5-0079
1
Start Cartridge
9-8213
3
Electrode
9-8215
5
30 Amp Tip
9-8206
5
40 Amp Standoff Tip
9-8208
5
40 Amp Standoff Tip
9-8208
5
60 Amp Standoff Tip
9-8210
1
Shield Cup Body
9-8237
1
Shield Cap, Machine, 40 Amp
9-8245
1
Shield Cap, Machine, 50-60 Amp
9-8238
1
Shield Cap, Deflector
9-8243
1
Ohmic Clip Kit
9-8224
1
Large O - Ring
8-3487
1
Small O - Ring
8-3486
