Appendix i: interconnecting diagram – Tweco Merlin 3000 Cutting Systems User Manual
Page 29

Manual 0-2475
25
APPENDIX
APPENDIX I: INTERCONNECTING DIAGRAM
A-00658
1
2
3
4
5
6
7
8
9
10 11 12 13 14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Output Connector (Front View)
Input Connector (Front View)
J3
J2
Torch (+)
Torch (-)
Coolant
Return
Secondary Gas
Torch (+)
Coolant
Return
Part of Input
Quick Disconnect
From Power Supply
Part of Output
Quick Disconnect
To Torch
