FEATURES
1. Laser sight on/off button
2. Laser sight aperture
3. Trigger switch
4. Blade sighting notch
5. Motor housing
6. Main handle
7. Front handle
8. Bevel adjustment lever
9. Bevel scale
10. Parallel guide locking knob
11. Parallel cutting guide 12. Blade guard lever
13. Retracting blade guard
14. Baseplate
15. Upper blade guard
16. Dust extraction chute
17. Depth locking lever
18. Cut depth scale
19. Blade
20. Pin wrench
21. Hex key
Features
18
6
15
4
14
13
10
2
7
1
5
16
12
19
8
11
9
20
3
17
21
