Monitor Menu
The monitor menu allows you to view the following temperatures and running
hours:
Outdoor temperature highs and lows
Room temperature highs and lows
Floor temperature highs and lows (requires floor sensor to be installed)
Heat W1 = Number of hours the thermostat is actively heating the room
To clear the temperature highs and lows or the running hours:
1. Touch the temperature or running hours.
2. Display will show “
”.
3. Touch Enter.
•
•
•
•
Toolbox Menu
This menu is provides advanced level information.
Access
Change the access level on the thermostat.
Status Info
Displays the current status of the thermostat including any overrides from the tekmarNet ®
system control. Toggles between “Status Info” and the current status.
System Normal = Thermostat is operating normally.
Override W1 = The tekmarNet
® system control is either forcing the heating W1
relay on or off.
WWSD = Warm Weather Shut Down is in effect.
Air Group Master Cool = Heating is off while the cooling system is on.
Optimum Start = Heating is started early in order to meet temperature setpoint
at Event 1 or Event 3.
Floor Max = The floor has reached its maximum temperature. Some under heating
could occur.
Floor Min = The floor is operating at its minimum temperature. Some over heating
could occur.
Baseload On = Baseload heating is on even though the room temperature is
satisfied. Reduces heat up time when the sun sets in the evening.
Software Version and Type Number
Display the software “SW” and the “TYPE” number.
•
•
•
•
•
•
•
•
