© 2009 U 544 - 02/09 4 of 12
Viewing Current Temperatures
Viewing the Room Set Temperature
Use the View menu to view the current temperatures being sensed by the thermostat. To view the available temperatures,
use the Menu button to go to the View menu. Use the Item button to view the temperatures.
The Room Set temperature is the temperature that the
thermostat is currently set to maintain.
To view the Room Set temperature:
1. Use the Menu button to select the View menu.
2. Use the Item button to select Room Set.
Room Temperature
This is the current air temperature of the room being
controlled.
Outdoor Temperature
If an outdoor sensor is connected, this is the current outdoor
air temperature.
Floor Temperature
If a floor sensor is connected to the thermostat, this is the
current floor temperature.
Remote Temperature
If a remote sensor is connected to the thermostat, this is
the current temperature at the remote sensor.
Adjusting the Room Set Temperature (No Schedule)
To adjust the Room Set temperature when there is no
schedule in use:
1. Make sure you are in the VIEW menu. If not, press the
Menu button until VIEW displays in the top left corner.
2. Press the Item button to display the ‘Room’ or ‘Room
Set’ item.
3. Press the Up or Down button to enter the ‘Set Heat’
mode. Continue pressing the Up or Down button until
the desired temperature is displayed
4. Ten seconds after the adjustment has been made, the
display will return to the default item.
Wait 10
seconds
Press Up or Down
Button to adjust the
heating temperature.
Press Up or Down
Button to adjust the
cooling temperature.
OR
