4. Wiring
5. Switch Settings
1 2 3 4
tN2 Manager, Module
or Wiring Center tN2 tN2
1 2 3 4
tNt 527
527
One Stage Heat
Mmm YYYY Lo
t # 1
23
45
Mee
ts Class B:
Canadian ICES FCC P
ar
t 1
5
10
23-0
1
tN2
1
tN2
2
Switch Se
ttings:
For instructions see brochure
Use at least 65°C conductors
ON
Se
tback
Scene Lock
No
t used
No
t used
Unlock Off Off
Switch
Setting
Location
Switch Position Action
1
ON
SETBACK Allow thermostat to respond to
available schedule. Requires Timer 033.
OFF OFF No setback schedule response.
2
ON
SCENE Allow thermostat to respond to
scenes. Requires User Switch 479.
OFF OFF No scene response.
3
ON
LOCK Locked to ‘User’ access level. Set to
Lock when installation completed.
OFF
UNLOCK Unlock to access all settings. Set
to Unlock during installation.
4
ON Not used
OFF Not used
