Snow / Ice Sensor Socket 091
Literature 090_D, 091_C
Packaged weight 1.5 lbs (670 g)
Socket material Silicon brass
Dimensions 3-13/16" H x 3-1/2" OD (97 mm H x 89 mm OD)
Approvals CSA C US with tekmar Snow/Ice Sensor 090
-Included
One polyethylene protective cap, one polyethylene mounting
plate and eight #6-32 x 3/8" screws
Snow / Ice Sensor 094 In-slab, 208 ft. (63 m) Wire
Literature 090_D, 094_C
Packaged weight 10.4 lb (4762 g)
Dimensions 1-3/4" H x 3-7/16" OD (45 mm H x 87 mm OD)
Sensor material Silicon brass
Cable Material
208 ft. (63 m) 5 conductor stranded wire with
polyethylene jacket
Approvals CSA C US with tekmar Snow Melting Controls
Operating range -30 to 170°F (-34 to 77°C)
Included
4 #4-40, 7/16" machined, stainless steel screws
4 #6-32, 3/8" flathead, slotted, stainless steel screws
Snow / Ice Sensor 090 In-slab, 65 ft. (20 m) Wire
Literature 090_D, 090_C
Packaged weight 4.4 lb (2000 g)
Dimensions 1-3/4" H x 3-7/16" OD (45 mm H x 87 mm OD)
Sensor material Silicon brass
Cable Material
65 ft. (20 m) 5 conductor stranded wire with
polyethylene jacket
Approvals CSA C US with tekmar Snow Melting Controls
Operating range -30 to 170°F (-34 to 77°C)
Included
4 #4-40, 7/16" machined, stainless steel screws
4 #6-32, 3/8" flathead, slotted, stainless steel screws
Technical Data
The Snow / Ice Sensor 090 (094) must be operated by a tekmar Snow Melting
Control 654, 661, 662, 664, 665 or 667. Operation of the sensor by 3rd party
control systems may result in electrolysis failures not covered by the tekmar
Limited Warranty.
