background image

DIRECTIONAL ARROW SWITCH

PAGE 1

PRODUCT SPECIFICATIONS

Pin #

Wire Color

Function

1

Red

+10-30 Vdc Power Input

2

White / Red

Master / Ignition switch (0u = Stand by)

3

Black

(-) Ground

4

NA

Not populated

Pin #

Wire Color

Function (All Outputs +Vdc Active High)

1

Blue

LEFT Arrow Indicator Output Control

2

Brown

CENTER Arrow indicator Output Control

3

Green

RIGHT Arrow Indicator Output Control

4

Yellow

WARNING 1 Output Control

5

Pink

WARNING 2 Output Control

6

Red/Black

Power Control Output to External Relay for Predator Bar

CN1 (2x2, Power Input Connector)

CN2 (2x3, Control Output Connector, Low Current: 0.25A Max)*

Input Voltage:

+10-30 Vdc

Polarity:

Negative Ground

Reverse Polarity Protection: Yes

Transient Protection:

Yes

Operating Temperature:

-40C to +85C

Current Draw:

0.8 Amps

Standby Current:

Zero Amps

+Vin Fuse:

5 Amps ATO

Dimensions

166mm x 22mm x 45mm (6.55" x 0.88" x 1.76")
170 mm (6.7") w/ Mounting Bracket

Shipping Weight

.65 lbs

Electrical

Mechanical

WIRE COLORS/USES

DIRECTIONAL ARROW SWITCH

PAGE 14

* Must NOT exceed a total of 0.25 Amp for any combination of active outputs.

NOTES:
