ENGLISH
20
B29. FX On advanced Mode
By using this button in advanced effect mode you can activate the effect.
Shift: FX 2. With this function it is possible to assign and activate the effect bank for player B. [Trak-
tor PRO]
B30. Dry/Wet Encoder
With the Dry/Wet encoder the effect rate can be faded in and out.
Shift: Loop +/-. By holding the shift button and simultaneously turning the Dry/Wet Encoder it is
possible to vary the Auto Loop bar length.
B31. Master Volume
With this controller the master output volume can be adjusted.
B32. Headphones Volume
With this controller the headphones volume can be adjusted.
B33. Cue Mix Fading
With the Cue Mix controller you can simulate a pre-mix via the headphones. In the right position you
can hear the master signal and in the left position you can hear the cue signal.
B34. kensington Lock
Standardized connection for theft protection.
B35. 6.3 mm Microphone Jack
You can connect a microphone with a 6.3 mm jack to this input.
B36. phono/Line Volume knob
Via this knob it is possible to adjust the Phono/Line input volume.
NOtE!
the volume can only be adjusted if the phono/Line routing Switch -B48- is in the Master position.
B37. Mic Volume knob
Via this knob it is possible to adjust the volume of a connected microphone.
NOtE!
the microphone signal is directly routed to the Master Output and it is also functional without
the usage of a software.
B38. 6.3 mm Headphones Input
You can connect headphones with a 6.3 mm jack to this input.
B39. Headphones Equalizer
With this equalizer it is possible to adjust the headphones‘ sound characteristics.
B40. Crossfader Curve
With this controller you can adjust the crossfading curve. The curve is steplessly adjustable from a
constantly increasing curve up to a hard adjustment.
B41. Mains Cord Strain relief
With this the cord will be relieved from strain.
B42. Mains Connection (mains adapter optionally available, DC 6V, 1,5A)
You can connect a mains adapter to this connection.
B43. On/Off Button
With this button you can turn the Digital Jockey 2 on and off respectively.
B44. uSB port
Connect your USB cord to this input.
ONLY INtErFaCE EDItION:
B45. audio Output (Master)
Connect your main sound system via RCA cord to this output.
B46. audio Input
An external sound source (e.g. CD player, turntable) can be connected to this input.
B47. phono/Line Switch
Depending on the connected sound source you can de-/activate the phono pre-amp.
