DESIGNatIONS ONLY FOr tHE INtErFaCE EDItION

B35. 6.3 mm Microphone Input
B36. Phono/Line Volume Knob
B37. Mic Volume Knob
B38. 6.3 mm Headphones Input
B39. Headphones Equalizer
B40. Crossfader Curve

B41. Mains Cord Strain Relief
B42. Mains Connection (mains adapter optionally available, DC 6V, 1,5A)
B43. On/Off Button
B44. USB Port
B45. Audio Output (Master)
B46. Audio Input
B47. Phono/Line Switch
B48. Phono/Line Routing Switch
B49. GND Grounding Screw

DIFFErENCES FOr traktOr LE

B50. FX Value Knob (Shift: Effect Select)
B51. Activate Buttons
B52. Tempo Fine Knob (Shift: Effect Select)
B53. Tap Button
B54. Effect On Button

B50

B51

B52

B53

B54

B41

B43

B44

B45

B46

B49

B47

B48

B42

B35

B37

B36

B40

B39

B38
