Kino Flo Blanket Light 6X6 DMX - Manual (Page 18)

18
KAS-6X6 KAS-6X6-F KAS-4MX
BLANKET-LITE Specifications:
Outside dimensions of BLANKET-LITE with
frame: 80" H x 80" W x 11" D
203 x 203 x 28cm
Weight of BLANKET-LITE w/ lamps: 26lbs/11.7kg
Weight of BLANKET-LITE w/ lamps and frame:
72.5lbs/32.6kg
Part Description Dimensions Weight Holds
Number (Empty)
KAS-6X6 Blanket-Lite 78.5 x 10.5 x 14” 30lb/13.5kg Blanket-Lite 6X6
Ship Case (199 x 26.5 x 35.5cm) (1)
KAS-6X6-F Blanket-Lite 74 x 9 x 12.5” 27lb/12.2kg Blanket-Lite
Frame Ship Case (188 x 23 x 32cm) Frame (1)
KAS-4MX Blanket-Lite DMX 25.5 x 16 x 20” 33lb/15kg Mega DMX
Ballast Mount (65 x 40.5 x 51cm) Ballasts (4)
and Ship Case Cables (4)
Mount (1)
KAS-72 6ft Lamp 71 x 10.5 x 11” 20lb/9kg 6ft Lamps (20)
Ship Case (180.5 x 26.5 x 28cm)
INS-L4 4-Lamp 24 x 9 x 1” N/A Fits KAS-72
Foam Pad (61 x 23 x 2.5cm)
