Brain Connections
Step 1
For wired applications, connect the Ethernet
cable between the Brain and computer or device
(skip for wireless device/applications).
Step 2
Install provided terminators on any unused con-
trol ports on the Brain, bricks or MCBs.
Step 3
Plug the AC power adapter into an AC
receptacle, then connect the power output cable
from the power supply to the Brain.
Step 4
Allow the Brain to initialize (multi-colored LEDs
will be visible at the Brain) and transition into a
ready state signified by a pulsing blue LED color.
Step 5
For wireless devices - set your device’s Wi-Fi
connection to be “CineDrive”
(skip this step for wired applications).
Step 6
Launch the kOS application.
Step 7
Verify the application is connected by confirming
the word “Online’” is present in the lower left of
the user interface. If it says “Connect” on red
font, double-tap/click on the word Connect and
the connection between the Brain and user
interface should occur.
Note- Both Windows and Mac require you to wait 60 seconds after the network con-
nection is made before kOS can connect to the Brain. You can monitor this on Win-
dows by hovering the mouse over the network icon in the task tray. While waiting for
this 60 seconds to expire, you’ll see the ‘Identifying’ message. Once the 60 seconds
has expired, you’ll see the ‘unidentified network’ message.
