Slider Motor Connections

Step 1

Connect the slider motor cable connector to the (Axis 1) Motor Control Box (MCB).

Step 2

Connect the provided 2’ control cable between the Brain and the slider motor MCB.

User Interface Software Download

*Keep kOS user interface closed until all connections have been made and Brain is

powered up.

iOS

Visit the Apple App Store and download the latest version of the kOS user interface

https://itunes.apple.com/us/app/kessler-kos/id603755857

Mac OS & Windows

Download desired kOS user interface to your computer or device from

http://kesslercinedrive.com/downloads/
