STEP 1
Begin by positioning the base section and tip section.
The T-Bar (control rod) should be underneath each
frame section (base & tip).
STEP 2
Slide the coupler bars into the base section so that the
holes line up. Insert the ¼”-20 bolts and apply the nuts
but do not tighten.
STEP 2B
If you purchased the optional tool less kit, line up the
holes and apply 2 of the tool less knobs but do not
tighten.
STEP 3
Slide the exposed coupler bars into the tip section and
insert the ¼”-20 bolts and apply the nuts. With socket
and wrench, tighten all four bolts.
STEP 3B
If you purchased the optional Tool Less kit, apply the
remaining (2) knobs and tighten all four knobs.
KC-5.5 and KC-8
ASSEMBLY INSTRUCTIONS
