Gossen Mavo-Spot 2 USB User Manual
Page 10
10
GOSSEN Foto- und Lichtmesstechnik GmbH
4.2
Measurements
Press the
key to select the Lumi function.
Look through the eyepiece on the MAVO-SPOT 2, and sharply focus
your measuring field with the focusing mechanism at the lens. Now
align the measuring circle reflected into the viewfinder to the point to be
measured. This point should be uniformly illuminated, and as large as
possible relative to the measuring circle.
Press the
key and read the measured value.
.
4.2.1
Overflow / Underflow Display
If the measuring range is exceeded, “----” appears at the display.
If the measuring range is fallen short of, “0.00” appears at the display.
