4 E-flite Piper L-4 Grasshopper ARF Assembly Manual
Landing Gear Installation
Required Parts
Fuselage assembly Landing gear
Required Tools and Adhesives
Medium CA
 1. Locate the landing gear. The gear will fit in the
two slots on the bottom of the fuselage. Note that
the straight edge and the wheels will be to the front
of the aircraft.
Use care not to damage the fuselage
when installing the landing gear.
 2. Press the landing gear in the slots in the bottom
of the fuselage. The landing gear should fit flush
against the fuselage.
 3. The landing gear will fit snugly into the slot
in the fuselage. If you do not plan to remove the
landing gear at any time then we suggest that you
tack glue it in the slot with medium CA. If you do
not glue the landing gear in, you will need to check
it periodically to make sure that it does not become
loose over time.
Servo Installation
Required Parts
Fuselage assembly Servo with hardware (2)
Required Tools and Adhesives
Phillips screwdriver: #00, #0
 1. Use a #00 Phillips screwdriver to remove the
servo horns from the rudder and elevator servos.
Set the horns and screws aside for later.
 2. Use the tab on the battery hatch to remove it
from the fuselage. Set the battery hatch aside in a
safe place for later.
