2 E-flite Piper L-4 Grasshopper ARF Assembly Manual
Product Registration
Register your product online at:
www.e-fliterc.com/register/
Contents of Kit/Parts Layout
EFL5026 Fuselage
EFL5027 Wing Panels L&R
EFL5028 Tail Set
EFL5029 Landing Gear
EFL5030 Cowling
EFL5031 Main Wheel Set
EFL5032 Windshields
EFL5033 Hardware
EFL5034 Pushrods
EFL5035 Main Struts
UltraCote ® Covering Colors
HANU874 Black
HANU0811 ParkLite ™ Olive Drab
HANU0816 ParkLite ™ Gray
HANU870 White
Introduction
Combining the compact size of a classic balsa free-
flight model with full 4-channel control, the Piper L-4
Grasshopper 250 is an exciting alternative to the usual
park flyer experience. Its exceptionally low parts count
and time saving features like the magnetically-secured
plug-in wings make assembly about as easy as it gets
for an ARF.
In the air, its docile flight characteristics and gorgeous
scale appearance will reward you with one of the most
enjoyable park flying experiences available. Plus, it’s
small enough and slow enough to fly in a large indoor
venue whenever the park isn’t an option.
Important Warranty Information
Please read our Warranty and Liability Limitations
section on Page 20 before building this product. If you
as the Purchaser or user are not prepared to accept the
liability associated with the use of this Product, you are
advised to return this Product immediately in new and
unused condition to the place of purchase.
Using the Manual
This manual is divided into sections to help make
assembly easier to understand, and to provide breaks
between each major section. In addition, check boxes
have been placed next to each step to keep track
of its completion. Steps with a single circle () are
performed once, while steps with two circles ( )
indicate that the step will require repeating, such as for
a right or left wing panel, two servos, etc.
Remember to take your time and follow the directions.
Age Requirements
Age Recommendation: 14 years or over. This is not
a toy. This product is not intended for use by children
without direct adult supervision.
Table of Contents
Introduction ........................................................... 2
Important Warranty Information .............................. 2
Using the Manual ................................................... 2
Age Requirements .................................................. 2
Product Registration................................................ 2
Contents of Kit/Parts Layout .................................... 2
UltraCote Covering Colors ...................................... 2
Recommended Radio Equipment ............................. 3
Optional Accessories .............................................. 3
Brushless Outrunner Setup ...................................... 3
Required Tools and Adhesives ................................. 3
Note on Lithium Polymer Batteries ........................... 3
Warning ................................................................ 3
Covering Warning ................................................. 3
Landing Gear Installation ........................................ 4
Servo Installation .................................................... 4
Receiver and Speed Control Installation ................... 5
Linkage Installation ................................................. 7
Motor and Cowling Installation for
use with Prop Saver........................................... 9
Motor and Cowling Installation for
use with Prop Adapter ..................................... 11
Battery Installation ................................................ 13
Front Windscreen Installation ................................ 13
Aileron Servo Installation ...................................... 14
Wing Attachment, Struts and
Top Windscreen Installation ............................. 17
Control Throws..................................................... 18
Center of Gravity ................................................. 19
Range Test Your Radio .......................................... 19
Flying Your L-4 Grasshopper ................................. 20
Safety Do’s and Don’ts for Pilots ............................ 20
Daily Flight Checks ............................................... 20
Warranty Information ........................................... 20
CE Compliance Information for
the European Union ........................................ 22
2009 Official Academy of
Model Aeronautics Safety Code ....................... 22
