Radio Installation
Required Parts
• Airframe • Cable crimp (8)
• Servo (3) • Long servo arm (3)
• Control cable • Hook and loop meterial
• Micro control horn w/backplate (2)
• Servo extension, 3" (76mm)
• Micro cable adjust connector (4)
• Aileron linkage, 5
3 /
4
" (146mm) (2)
• Aileron interconnect linkage, 9 1 /
4
" (235mm) (2)
• Micro control connector w/nylon backplate and
2mm x 3mm screw (8)
Required Tools and Adhesives
• Foam-safe CA • Pliers (for crimping)
• Hot glue • Low-tack tape
• Phillips screwdriver (small)
 5. Attach the propeller using the propeller adapter
included with the motor.
 6. Secure the speed control location using double-
sided tape or hook and loop. Exact speed control
location may vary, depending on the brand used
and the center of gravity.
