Control Drive Assembly
Page 13
Item No. Quantity
Part No.
Description
.
1...................1....................18697.......................Backplate, Hinged, 2900
.
2...................1.....................................................Timer:
- 3200 7 Day
.
.
.
.
.
- 3200 12 Day
.
.
.
.
.
- 3210 Meter
.
3...................1....................11839.......................Power Cord, 12’ Fleck
.
4...................1....................13547.......................Strain Relief, Flat Cord
.
5...................1....................40400.......................Harness, Drive, Designr/Envirmtl
.
6...................1....................41543.......................Motor, Drive, 115V, 50/60 Hz
.
7...................1....................60160-15..................Drive Cam Assy, STF, Blue, 2900
.
8...................2....................10338.......................Pin, Roll, 8/32 x 7/8
.
9...................2....................10231.......................Screw, Slot Hex, 1/4 - 20 x 1/2
.
10.................2....................10302.......................Insulator, Limit Switch
.
11.................2....................10218.......................Switch, Micro
.
12.................2....................14923.......................Screw, Pan Hd Mach, 4-40 x 1
.
13.................2....................12777.......................Cam, Shut-Off Valve
.
14.................1....................10909.......................Pin, Link
.
Not Shown:
.
.
2....................10300.......................Screw, Slot Hex Wsh, 8-18 x 3/8
..
.
1....................13741.......................Plug, 3/4”, Knock-Out
.
.
1....................15806.......................Plug, Hole, Heyco #2693
.
.
1....................16493.......................Plug, Hole, Heyco
.
.
1....................17421.......................Plug, 1.20 Hole Heyco #2733
.
.
2....................19691.......................Plug, .750 Dia, Recessed, Black
.
.
7....................19800.......................Plug, .140 Dia, White
..
.
4....................19801.......................Plug, .190 Dia, White
.
.
1....................10872.......................Screw, Hex Wsh, 8-32 x 17/64
For Service Assembly Numbers, See the Back of this Manual
