Capacity, Dimensions - weights, Pressure – temperature – Watts P60 User Manual
Page 2: Standards, Materials, Reduced pressure range
NOTE: 1psi equals .07 bar
1 gpm equals 3.785 liters per minute
Capacity
Capacity - P60-M1
100PSI (6.9 bars) Inlet Pressure
psi
100
90
80
70
60
50
40
30
20
10
0
Flow G.P.M.
Reduced Pressure
0.5
1.0 1.5 2.0 2.5 gpm
1.9
3.8 5.7 7.5 9.5 lpm
kPa
689
620
551
482
413
345
276
207
138
69
0
C Spring
B Spring
A Spring
A
C
d
B
Reduced Pressure Range:
OPTION SuFFIx
RANGE
psi
Bar
A
0-25
0-1.76
B
0-60
0-4.22
C
0-125
0-8.79
Dimensions - Weights
MOdEL
SIzE (dN)
A
B
C
d
max
d
min
WEIGHT
in.
mm.
in.
mm.
in.
mm.
in.
mm.
in.
mm.
in.
mm.
lbs
kgs
P60-M1
1
⁄
4
8
1
9
⁄
16
40
3
⁄
4
19
11
⁄
16
17
2
3
⁄
16
56
2
3
⁄
4
70
.25
.11
Pressure – Temperature
Temperature Range: 33ºF-150ºF (0.5ºC - 66ºC)
Maximum Inlet Pressure: 300psi (20.7 bar)
Reduced Pressure Range:
Standards
Certified by NSF to NSF standard 61.
Materials
Body:
NSF grade Noryl
®
thermoplastic
Seat:
NSF grade PES (Poly-Ether–Sulfone)
Spring Cage:
NSF grade Acetal thermoplastic
Adjusting Screw: NSF grade Acetal thermoplastic
Disc:
Buna-N (FDA)
Diaphragm:
Buna-N (FDA)
Bottom Plug:
P60:NSF grade Acetal thermoplastic
O-Ring Seals:
Buna-N (FDA)/EPDM (FDA)
Bottom Spring: 300 series stainless steel
Stem:
300 series stainless steel
Noryl
®
is a registered trademark of SABIC Innovative Plastics™.
ES-P60 1323
© 2013 Watts
USA: Tel: (978) 688-1811 • Fax: (978) 794-1848 • www.watts.com
Canada: Tel: (905) 332-4090 • Fax: (905) 332-7068 • www.watts.ca
A Watts Water Technologies Company
