assembly instructions
Item No. 4771
477
1
start here
page 2
1. Find a clear area in which you can work.
2. Unpack fixture and glass from carton.
3. Carefully review instructions prior to assembly.
01.01.13
1. To complete assembly, first thread bottom finial (3) with crystal (F) attached onto
bottom of fixture - see Drawing 2.
2. Proceed to attach crystals using Drawing 2 as a reference quide. If a crystal must
be replaced, please use the part no.s provided below the crystal drawings when
ordering.
3. The crystals are referenced with the quantity ( Ex. ? x 6) required following the
letter.
R4771CRY-C R4771CRY-B R4771CRY-A
B C A
R4772CRY-C
D
CRYSTAL INDENTIFICATION
A X 4
A X 4
A X 4 B X 4
C X 4
D
ATTACHED
TO FINIAL
