H I N K L E Y L I G H T I N G 12600 Berea Road Cleveland, OH 44111 800.446.5539 / 216.671.3300 www.hinkleylighting.com
assembly instructions
Family: Midtown Item No. 4978 BN
1. Find a clear area in which you can work.
2. Unpack fixture and glass from carton.
3. Carefully review instructions prior to assembly.
*** The construction of this fixture will be accomplished by first assembling the
main body of the fixture, making all necessary electrical connections, hanging
the fixture from the ceiling, and then installing the glass.
start here
4978
Note: Maximum wattage for 4978 fixture is 100 watts per bulb.
SAFETY WARNING: READ WIRING AND GROUNDING INSTRUCTIONS (I.S. 18)
AND ANY ADDITIONAL DIRECTIONS. TURN POWER SUPPLY OFF DURING
INSTALLATION. IF NEW WIRING IS REQUIRED, CONSULT A QUALIFIED
ELECTRICIAN OR LOCAL AUTHORITIES FOR CODE REQUIREMENTS.
1. To assemble main body, slip center column (1) along wire and thread into coupler (2)
and tighten - see Drawing 1.
2. Please refer to the hanging instruction sheet (I.S. 19) provided to hang this fixture.
Then refer back to this sheet to install the glass.
1. Fixture can now be lamped accordingly.
2. Slip glass (3) over socket and into glass holder (4).
Drawing 1 - Fixture Assembly
1
3
4
2
4.28.10
