assembly instructions
Item No. 1491
1. Find a clear area in which you can work.
2.
3. Carefully review instructions prior to assembly.
star t here
1491
SAFETY WARNING: READ WIRING AND GROUNDING INSTRUCTIONS (I.S. 18)
AND ANY ADDITIONAL DIRECTIONS. TURN POWER SUPPLY OFF DURING
INSTALLATION. IF NEW WIRING IS REQUIRED, CONSULT A QUALIFIED
ELECTRICIAN OR LOCAL AUTHORITIES FOR CODE REQUIREMENTS.
(I.S.
18) and follow all instructions to make all necessary wiring connections. Then refer back to this
Drawing 1 - Fixture Mounting
Drawing 2 - Glass Installtion
1. Fixture is mounted using 3 screws.
2. Make all necessary electrical connections following wiring instructions below.
Glass Installation Instructions - see Drawing 2.
1. (A) over top of pre-installed post (B) making
sure all wire connections are tucked inside the pole - see Drawing 1.
2. the top edge of
3. Thread the 3 set screws (C)
4. Tighten screw (C)
5.
(3) from top of roof (2) and remove roof (2) from main
body (1) - see Drawing 2.
6. Fixture can now be lamped accordingly.
7. To reassemble, follow step 5 in reverse order.
6.1.12
e s t . 1 9 2 2
1
2
3
5
4
6
1. Unthread top finial (3) from the top of the fixture, and remove roof (2).
2. Remove retainer screw (5) that secures glass clip (4) to cage (1). Set parts aside.
3. Slip glass panel (6) into cage, replace glass clip (4) and thread retainer screw (5) back in, to secure
glass panel (6). Repeat for remaining panels.
4. Lamp fixture and replace roof (2) to complete assembly.
NOTE: Customer has option of installing clear seedy glass panels, or
amber linen glass panels.
