Hinkley Lighting DILLON 3663BN - Manual

assembly instructions
Item No. 3663
1. Find a clear area in which you can work.
2. Unpack fixture and glass from carton.
3. Carefully review instructions prior to assembly.
star t here
3663
*** The construction of this fixture will be accomplished by first assembling the main body,
hanging the fixture, and then installing the fixture glass.
2
3
SAFETY WARNING: READ WIRING AND GROUNDING INSTRUCTIONS (I.S. 18)
AND ANY ADDITIONAL DIRECTIONS. TURN POWER SUPPLY OFF DURING
INSTALLATION. IF NEW WIRING IS REQUIRED, CONSULT A QUALIFIED
ELECTRICIAN OR LOCAL AUTHORITIES FOR CODE REQUIREMENTS.
6.1.12
Drawing 1 - Fixtu re Assembly
Drawing 2 - Fixture Assembly
1. To assemble main body (1), spread arms (A) until they are equally spaced 120 degrees apart
- see Drawing 1.
2. After arms (A) are positioned correctly the fixture may be mounted to the ceiling. Please refer
to instruction sheet (IS19-91) provided to install fixtuure.
3. After installation is complete refer back to this instruction sheet on how to attach the glass.
12
120º
A
A
A
1. To install glass, remove socket ring (3) from the socket (1) - see Drawing 2.
2. Slip glass (2) over socket (1).
3. Thread socket ring (3) onto socket (1) and tighten.
4. Fixture can now be lamped accordingly
3
2
1
