Hinkley Lighting SLOAN 4546RB User Manual
Start here, Assembly instructions

assembly instructions
Family: Sloan Item No. 4546RB
1. Find a clear area in which you can work.
2. Unpack fixture and glass from carton.
3. Carefully review instructions prior to assembly.
1.
2.
Slip loop (2) along wire and thread onto top of main body (1) - see Drawing 1.
3.
Make sure all candle sleeves (3) are slipped over the sockets (A).
Please refer to the hanging instruction sheet (I.S. 19) provided to hang fixture. Then
refer back to this sheet to continue installation of this fixture.
1. To install shades, slip shade cup (4) onto top of candle sleeve (3) - see Drawing 1
.
2. Fixture can now be lamped accordingly.
*** The construction of this fixture will be accomplished by first rotating the fixture
arms into the correct position, assembling the basic fixture, installing the mounting
hardware, making all necessary electrical connections, hanging the fixture, and then
installing the shades.
start here
4546
SAFETY WARNING: READ WIRING AND GROUNDING INSTRUCTIONS (I.S. 18)
AND ANY ADDITIONAL DIRECTIONS. TURN POWER SUPPLY OFF DURING
INSTALLATION. IF NEW WIRING IS REQUIRED, CONSULT A QUALIFIED
ELECTRICIAN OR LOCAL AUTHORITIES FOR CODE REQUIREMENTS.
Drawing 1 - Fixture Assembly
3
4
3
2
1
A
01.01.11
H I N K L E Y L I G H T I N G 33000 Pin Oak Parkway Avon Lake, OH 44012 800.446.5539 / 440.653.5500 hinkleylighting.com
