Start here, Assembly instructions

background image

assembly instructions

Family: Wabash Item No. 1332 MB/MO

1. Find a clear area in which you can work.
2. Unpack fixture and glass from carton.
3. Carefully review instructions prior to assembly.

*** the construction of this fixture will be accomplished by first assembling
the main body of the fixture, making all necessary electrical connections,
and then hanging the fixture from the ceiling.

start here

1332

Note: Maximum wattage for 1332 fixture is 40 watts per bulb.

SAFETY WARNING: READ WIRING AND GROUNDING INSTRUCTIONS (I.S. 18)
AND ANY ADDITIONAL DIRECTIONS. TURN POWER SUPPLY OFF DURING
INSTALLATION. IF NEW WIRING IS REQUIRED, CONSULT A QUALIFIED
ELECTRICIAN OR LOCAL AUTHORITIES FOR CODE REQUIREMENTS.

1. Prior to assembling the main body, fixture can be lamped accordingly.
2. To assemble main body, attach the top cover (A) to the cage (C) by securing with
screws (B).
3. Please refer to the hanging instruction sheet (I.S. 19) provided to hang fixture.

A

C

Drawing 1 - Fixture Assembly

B

B

2.7.08
