H I N K L E Y L I G H T I N G 33000 Pin Oak Parkway, Avon Lake, OH 44012 800.446.5539 www.hinkleylighting.com
assembly instructions
Item No. 1982
1. Find a clear area in which you can work.
2. Unpack fixture and glass from carton.
3. Carefully review instructions prior to assembly.
*** The construction of this fixture will be accomplished by first making all necessary
electrical connections, and then hanging the fixture from the ceiling.
star t here
1982
SAFETY WARNING: READ WIRING AND GROUNDING INSTRUCTIONS (I.S. 18)
AND ANY ADDITIONAL DIRECTIONS. TURN POWER SUPPLY OFF DURING
INSTALLATION. IF NEW WIRING IS REQUIRED, CONSULT A QUALIFIED
ELECTRICIAN OR LOCAL AUTHORITIES FOR CODE REQUIREMENTS.
Make electrical connections from supply wire to fixture lead wires. Refer to instruction sheet (I.S.
18) and follow all instructions to make all necessary wiring connections.
Then refer to the hanging instruction sheet (I.S.) provided to complete installation
of this fixture.
Drawing 1 - Glass Replacement
Glass Replacement Instructions - see Drawing 1.
1. Remove roof (2) from cage (1) by unscrewing the phillips heads screws (3) on top edge of roof.
2. Remove the glass clips (4) by removing the screws (5) that hold them in place.
3. Pull up on glass panel (6) and remove.
4. To replace the glass follow steps 1-3 in reverse order.
6.1.12
11
14
15
13
12
6
