Hinkley Lighting PEMBROOK 2082 User Manual
Start here, Assembly instructions

assembly instructions
Family: Pembrook Item No. 2082
1. Find a clear area in which you can work.
2. Unpack fixture and glass from carton.
3. Carefully review instructions prior to assembly.
*** The construction of this fixture will be accomplished by first making all
necessary electrical connections, hanging the fixture from the ceiling, and then
installing the glass.
start here
2082
SAFETY WARNING: READ WIRING AND GROUNDING INSTRUCTIONS (I.S. 18)
AND ANY ADDITIONAL DIRECTIONS. TURN POWER SUPPLY OFF DURING
INSTALLATION. IF NEW WIRING IS REQUIRED, CONSULT A QUALIFIED
ELECTRICIAN OR LOCAL AUTHORITIES FOR CODE REQUIREMENTS.
1. Please refer to the hanging instruction sheet (I.S. 19) provided to hang this fixture.
Then refer back to this sheet to install the glass.
Drawing 1 - Fixture Assembly
6.01.11
1
2
3
1. Fixture can now be lamped accordingly.
2. The glass in this fixture is installed by lining up the grooves (3) in the glass with
the tabs located inside the roof (1) - see Drawing 1 .
3. To install glass (2) align grooves and slip glass up into roof. Turn glass to
lock it in place.
