BRT-2X2
• Square, acrylic target
• Reflectivity factor: 1.0
• Max. temperature: +50°
C (+122º F)
• Optional brackets are
available
• Approximate size: 51 mm
x 51 mm
51 mm
(2.0")
56 mm
(2.2")
51 mm
(2.0")
30 mm
(1.2")
10 mm
(0.4")
4.2 mm x 14.2 mm Slot (2)
(0.16" x 0.56")
61 mm
(2.4")
3.5 mm
(0.14")
Clear
Acrylic
Lens
8.9 mm
(0.40")
BRT-36X40BM
• Rectangular, acrylic tar-
get
• Reflectivity Factor: 1.2
• Max. Temperature: +50°
C (120° F)
• Approximate size: 51 mm
x 51 mm
• Micro-prism geometry
61 mm
(2.4")
51 mm
(2.0") 40 mm
(1.6")
10 mm
(0.4")
10 mm
(0.4") 20 mm
(0.8")
4.3 mm
(0.16")
7 mm
(0.3")
51 mm
(2.0")
38 mm
(1.5")
3.5 mm
(0.14")
Clear
Acrylic
Lens
BRT-77X77C
• Square, acrylic target
• Reflectivity Factor: 2.0
• Temperature: –20° to
+60° C (−4° to +140° F)
• Optional brackets are
available
• Approximate size: 84.5
mm x 84.5 mm
84.5 mm
(3.3")
77 mm
(3.0")
77 mm
(3.0")
3.5 mm
(0.13")
84.5 mm
(3.3")
9 mm
(0.4")
Clear
Acrylic
Lens
BRT-TVHG
• Reflectivity factor: 0.8
• Max. Temperature: +60ºC
(+140ºF)
Retroreflective tape is availa-
ble in a variety of sizes and
shapes; see your Banner Cat-
alog for more information.
Not recommended for use with
clear object detection sensors.
5-Pin Euro-Style Cordsets
5-Pin Threaded M12/Euro-Style Cordsets
Model Length Style Dimensions Pinout
MQDC1-501.5 0.50 m (1.5 ft)
Straight
44 Typ.
ø 14.5
M12 x 1
2
3
4
1
5
1 = Brown
2 = White
3 = Blue
4 = Black
5 = Gray
MQDC1-506 1.83 m (6 ft)
MQDC1-515 4.57 m (15 ft)
MQDC1-530 9.14 m (30 ft)
MQDC1-506RA 1.83 m (6 ft)
Right-Angle
32 Typ.
[1.26"]
30 Typ.
[1.18"]
ø 14.5 [0.57"]
M12 x 1
MQDC1-515RA 4.57 m (15 ft)
MQDC1-530RA 9.14 m (30 ft)
