SIGNAL (red) LED lights whenever the sensor sees its
modulated light source
Construction
Molded thermoplastic polyester housing, o-ring sealed
transparent Lexan® top cover, molded acrylic lenses,
and stainless steel hardware. Q45s are designed to
withstand 1200 psi washdown. The base of cabled
models has a 1/2-inch NPS integral internal conduit
thread.
Maximum relative humidity: 90% at 50 °C (non-con-
densing)
Connections
PVC-jacketed 2 m (6.5 ft) or 9 m (30 ft) cables, or 4-pin
Euro-style quick-disconnect (QD) fitting are available.
QD cables are ordered separately. See Accessories.
Lexan® is a registered trademark of General Electric Co.
Design Standards
Q45AD9 Series sensors comply with the following standards:
ATEX (European) EN 60079-0, EN 60079-11, EN 60079-26
Canadian CAN/CSA C22.2 No. 0-M91, No. 142-M1987, No.157-92, No. 1010.1, E60079-0, E60079-11
United States FM Class 3600, 3610, and 3810, ANSI/ISA 61010-1 (82.02.01), ANSI/ISA 60079-0, 60079-11, and 60079-26
Certifications
Approvals
ATEX (European) II 1 G Ex ia IIC T5 Ta = -40°C to 70°C - 38343
Entity; FM12ATEX094X
Entity Parameters: V
Max
= 15 V dc, I
Max
= 60 mA, C
i
= 0.3 μF, L
i
= 0 mH
Canada Intrinsically safe for Class I, II and III, Division 1, Groups A, B, C, D, E, F and G T5 Ta = -40°C to 70°C -
38343;
Entity Non-incendive for Class I, Division 2, Groups A, B, C and D, T5 Ta = -40°C to 70°C Intrinsically safe
for Class I, Zone 0 Ex ia Group IIC T5 Ta = -40°C to 70°C - 39616; Entity
Entity Parameters: V
Max
= 15 V dc, I
Max
= 60 mA, C
i
= 0.3 μF, L
i
= 0 mH. a = Sensing mode D, DL, F, FP,
FV, LV, LP, CV, CV4 or R. b = Connection method Q or blank.
United States Intrinsically safe for Class I,II and III, Division 1, Groups A, B, C, D, E, F and G T5 Ta = -40°C to 70°C -
38343; Entity Non-incendive for Class I, Division 2, Groups A, B, C and D, T5 Ta = -40°C to 70°C Suitable
for Class II and III, Division 2, Groups F and G*, T5 Ta = -40°C to 70°C
Intrinsically safe for Class I, Zone 0 AEx ia Group IIC T5 Ta = -40°C to 70°C; Entity
*Class II and III, Division 2 applies only to model numbers ending in a Q suffix. Entity Parameters: V
Max
= 15
V dc, I
Max
= 60 mA, C
i
= 0.3 μF, L
i
= 0 mH. a = Sensing mode D, DL, F, FP, FV, LV, LP, CV, CV4 or R. b =
Connection method Q or blank.
Special Conditions for Safe Use:
Parts of the enclosure are non-conducting and may generate an ignition-capable level of ESD.
Cleaning of the equipment shall be done only with a damp cloth.
Q45 NAMUR Sensors
