Performance Curves
Visible Red Beam Models
Beam Pattern Excess Gain
Performance based on 90% reflectance white card test
VS1...CV10
VS1...CV20
Y: Beam Pattern X: Distance Y: Excess Gain X: Distance
Infrared Beam Models
Beam Pattern Excess Gain
Performance based on 90% reflectance white card test
VS1...C10
VS1...C20
Y: Beam Pattern X: Distance Y: Excess Gain X: Distance
