FI22FP Low-Profile Inline Plastic Fiber Optic Sensor
Hookups
Cabled Models Quick-Disconnect Models
bn
Remote
Teach
bu
wh
bk
gy
+
10 - 30V dc
–
Load
Load 100 mA max. load
bn
Remote
Teach
Note: Pink wire not used
bu
wh
bk
gy
+
10 - 30V dc
–
Load
Load 100 mA max. load
Quick-Disconnect Cables
Style Model Length Dimensions Pinout
6-pin
Pico-style
straight
PKG6Z-2
PKG6Z-
2 m (6.5')
9 m (30')
6-pin
Pico-style
right-angle
PKW6Z-2
PKW6Z-
2 m (6.5')
9 m (30')
28 mm max.
(1.1")
ø 10 mm max.
(0.4")
20 mm
(0.8")
25 mm max.
(1.0")
ø12 mm max.
(0.5")
Brown Wire
Gray Wire
Pink Wire
Blue Wire
Black Wire
White Wire
NOTE: Pink wire not used
