3.2 Initial installation
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
14
￭￭￭￭￭￭￭￭
850 Professional IC – AnCat – MSM-HC – MCS
￭
Connect a part of the 6.1803.040 PTFE capillary with a
6.2744.090 long pressure screw to the input of the sample
degasser. Guide the other end out of the instrument through a
capillary feed-through and connect it to the Sample Processor.
￭
Guide the sample outlet capillary connected to the sample output
of the injection valve out of the instrument through a capillary
feed-through and onward to the waste container and then fasten
it there.
5 Installing the peristaltic pump
(see Chapter 3.17.2, page 56).
￭
Connect the 6.1803.020 aspirating capillary for regeneration solu-
tions with a 6.2744.034 tubing olive and a 6.2744.070 short
pressure screw to the aspiration end of the 6.1826.320 pump
tubing for the regeneration solution.
￭
Place the pump tubing in a tubing cartridge.
￭
Connect the 6.1803.020 aspirating capillary for rinsing solutions
with a 6.2744.034 tubing olive and a 6.2744.070 short pressure
screw to the aspiration end of the second 6.1826.320 pump tub-
ing for the rinsing solution.
￭
Place the second pump tubing in the second tubing cartridge.
￭
Place both tubing cartridges into the peristaltic pump.
6 Connecting the MSM-HC
￭
Connect the capillary labeled with H2SO4 with a 6.2744.180
pump tubing connection and a 6.2744.070 short pressure screw
to the peristaltic pump on the outlet end of the pump tubing for
the regeneration solution.
￭
Connect the capillary labeled with H20 with a 6.2744.180 pump
tubing connection and a 6.2744.070 short pressure screw to the
peristaltic pump on the outlet end of the pump tubing for the
rinsing solution.
￭
Guide the two capillaries labeled with Waste into a waste con-
tainer and fasten them there.
7 Connecting the instrument
￭
Connecting the instrument to the PC with a 6.2151.020 USB
cable (see Chapter 3.20.1, page 66).
￭
Connect instrument to mains supply (see Chapter 3.20.2, page
66).
