2.1 Front

■■■■■■■■■■■■■■■■■■■■■■

6

■■■■■■■■

872 Extension Module Suppression – MCS

2 Overview of the instrument

2.1

Front

1

2

4

3

Figure 1

Front 872 Extension Module Suppression – MCS

1

Peristaltic pump
(see Chapter 3.5, page 15)

2

MCS
(see Chapter 3.7, page 26)

3

Standby indicator

4

Suppressor drive
(see Chapter 3.6, page 21)
