2 Overview of the instrument
876 Dosimat plus
￭￭￭￭￭￭￭￭ 7
1
2
5
4
3
Figure 2 Rear 876 Dosimat plus
1 Type plate
Contains specifications concerning mains
voltage and serial number. 2 Mains connection socket
3 USB (OTG) connector
For connecting printers, USB sticks, USB
hubs, etc. 4 MSB connector
Metrohm Serial Bus.
For connecting a stirrer or an 805 Dosimat.
Mini DIN, 9-pin.
5 Remote connector
For connecting the Manual Dosing Control-
ler or instruments with a remote interface.
D-Sub, 9-pin.
