￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 7 Technical specifications
882 Compact IC plus – Cation ￭￭￭￭￭￭￭￭ 67
￭ The pump is automatically shut down at the first piston stroke
above the maximum limit value
Minimum pres-
sure limit ￭ Adjustable from 0…49 MPa (0…490 bar)
￭ The shutdown mechanism is inactive at 0 MPa
￭ The shutdown mechanism only becomes active 2 minutes after sys-
tem start
￭ The pump is automatically shut down after 3 piston strokes below
the minimum pressure limit
7.7 Injection valve
Actuator time typ.100 ms
Max. operating
pressure 35 MPa (350 bar)
Material PEEK
7.8 Mains connection
Required voltage 100…240 V ± 10 % (auto-sensing)
Required fre-
quency 50…60 Hz ± 3 (auto-sensing)
Power consump-
tion ￭ 65 W for typical analysis application
￭ 25 W standby (conductivity detector to 40 °C)
Power supply unit ￭ Up to 300 W maximum, electronically monitored
￭ internal fuse 3.15 A
7.9 Interfaces
USB
Input 1 USB upstream, type B (for connection to the PC)
Output 2 USB downstream, type A
MSB 2 MSB MiniDin 8-pin (female) (for Dosino, stirrer, remote lines, …)
Caution
When connecting an instrument to the MSB connector you must
switch off the 882 Compact IC plus.
Detector 1 DSUB-15-pin high density (female)
